F6 Series LED Headlight Bulb
Features
- The heat sink measures 35mm in diameter and 36mm in height, with a power rating of 45W, ensuring optimal cooling performance.
- The unique S-shaped fins and high-quality AL6063 material (European standard) provide enhanced heat dissipation.
- Features double-sided copper base plates (1.5mm) and an external driver with smart temperature control, ensuring optimal protection for the LED chips.
- With a sleek, patented design, the bulb is small but powerful, offering EMC and decoding functions for advanced performance.
Specification
| Series |
F6 |
| Model |
F6 H1 |
F6 H4 |
F6 H7 |
F6 H11 |
F6 9005 |
F6 9006 |
F6 9012 |
| Voltage (V) |
DC9.6-60 |
| Power (W) |
45 |
| Luminous Flux (lm) |
3800 |
| Color temperature (K) |
6500 |
| Driver |
External driver |
| Fan |
Yes |
